Skid Steer-Mounted Trencher

HW60

Skid steer-mounted wheel trencher

Available to purchase through TrenchWorks in New Zealand

Best For

Suited to These Applications

Fibre optic installation
Utilities
Urban and hard-surface trenching

The HW60 mounts to a high-flow skid steer loader, delivering fast, narrow trenching through concrete, asphalt and cement-stabilised soils with minimal road disruption — ideal for fibre optic installation on hard surfaces in busy streets and urban environments.

Why Consider It

Up to 5x faster than excavator bucket work
Minimal road disruption — works without full closures
58 bullet-tooth rock wheel cuts concrete and asphalt
Produces uniform trench walls and a flat bottom for cable laying

Works With

Skid steer, high-flow hydraulics

Trenching Depth

0.6m (0.7m optional)

Trenching Width

50 / 75 / 100 / 125 / 200mm

Specifications

Carrier Requirement: Skid steer, high-flow hydraulics
Hydraulic Supply: 110–150 L/min at 220 bar
Maximum Digging Depth: 0.6m (0.7m optional)
Trench Width: 50 / 75 / 100 / 125 / 200mm
Output: 250–500 metres/day
Weight: Approx. 1,300kg

Is This the Right Machine for Me?

The HW60 is built for skid steer, high-flow hydraulics, trenching to 0.6m (0.7m optional) at widths of 50 / 75 / 100 / 125 / 200mm. If your project sits within that range it's a strong candidate — but ground conditions, site access and the exact outcome you need all matter too. Use the Find My Trencherquiz (on the right on desktop, or in the menu on mobile) for a starting recommendation, then talk to TrenchWorks to confirm it's right for your site before you buy. See the Trenchers NZ buying guide for how this machine compares across the full range.
