Tractor-Mounted Wheel Trencher

Wizz Wheel 75

Ultra-fast wheel trencher for fibre optic and utility installation

Available to purchase through TrenchWorks in New Zealand

Best For

Suited to These Applications

Fibre optic installation
Drainage
Irrigation
Water pipelines
Hard ground and rocky conditions

The Wizz Wheel 75 delivers the fastest, narrowest cuts in the range, with rock wheel capability for material as hard as basalt. Built for 130+ hp tractors, it's engineered for long-distance fibre optic networks and utility installation through the toughest hard-ground conditions, including asphalt and crushed concrete.

Why Consider It

Up to 750 metres/hour in easy ground conditions
Rock wheel capable to grade 6 on the Mohs hardness scale
Fastest, narrowest cutting in the AFT range
Soil blade, carbide or bullet teeth options for any ground

Works With

130+ hp, CAT3 linkage

Trenching Depth

0.75m

Trenching Width

50–150mm

Watch It Working

Specifications

Tractor Requirement: 130+ hp, CAT3 linkage
Maximum Digging Depth: 0.75m
Trench Width: 50–150mm
PTO: 6 spline, 540 RPM
Output: 100–750 metres/hour (ground dependent)
Weight: Approx. 2,000kg

Is This the Right Machine for Me?

The Wizz Wheel 75 is built for 130+ hp, cat3 linkage, trenching to 0.75m at widths of 50–150mm. If your project sits within that range it's a strong candidate — but ground conditions, site access and the exact outcome you need all matter too. Use the Find My Trencherquiz (on the right on desktop, or in the menu on mobile) for a starting recommendation, then talk to TrenchWorks to confirm it's right for your site before you buy. See the Trenchers NZ buying guide for how this machine compares across the full range.
