Excavator-Mounted Trencher

MH100

Large excavator-mounted trencher for difficult access and civil engineering

Available to purchase through TrenchWorks in New Zealand

Best For

Suited to These Applications

Civil infrastructure
Fibre optic installation
Water pipelines
Utilities
Difficult access sites

The MH100 turns a 20+ tonne excavator into the most versatile trenching solution for demanding conditions. A 360° turntable allows angled trenching against barriers and on slopes where a dedicated trencher can't go, digging five to ten times faster than a bucket while crushing or pulling stones up to football-size out of the trench.

Why Consider It

Digs 5–10x faster than a digging bucket
360° turntable for angled trenching near barriers and slopes
Crushes, grinds or pulls out stones up to football-size
Clean, professional trench with rapid backfilling

Works With

20+ tonnes

Trenching Depth

1.0m – 1.8m (staged options)

Trenching Width

125–400mm (standard/bullet chain)

Specifications

Excavator Requirement: 20+ tonnes
Hydraulic Supply: 200–225 L/min at 300–350 bar
Maximum Digging Depth: 1.0m – 1.8m (staged options)
Trench Width: 125–400mm (standard/bullet chain)
Digging Speed: 25–150 metres/hour (ground dependent)
Weight: Approx. 1,900kg

Is This the Right Machine for Me?

The MH100 is built for 20+ tonnes, trenching to 1.0m – 1.8m (staged options) at widths of 125–400mm (standard/bullet chain). If your project sits within that range it's a strong candidate — but ground conditions, site access and the exact outcome you need all matter too. Use the Find My Trencherquiz (on the right on desktop, or in the menu on mobile) for a starting recommendation, then talk to TrenchWorks to confirm it's right for your site before you buy. See the Trenchers NZ buying guide for how this machine compares across the full range.
